Designing For Traceability
The Need For Traceability
When working with complex micro-services, which typically (by design) have no graphical user interface, just agreed API definitions and service levels, there is a need to provide traceability so that technical support queries can easily be answered and system behaviour can be understood.
Designing for traceability from the outset enables the journey of individual service requests to be fully traced through the various nested micro-service calls and/or asynchronous processes that may ensue to determine the overall outcome of requests.
While successful outcomes rarely generate technical support queries, unsuccessful outcomes or delays may well do so and therefore it's helpful to understand exactly what happened to a request or, more often, where and why something went wrong.
Trace data makes it easier to debug deployments, integration issues and performance bottlenecks and also helps improve the design of processes to make them more robust, self-healing and performant as well as answer "search and rescue" queries from technical support.
Implementing Traceability
Traceability doesn't happen by accident. You need a common strategy for how your different components and services will log their various activities and interactions and allow those disparate interactions to be linked together across nested calls and/or asynchronous processes.
Processing may involve calling into external services that you don't own but whose outcome you need to understand. The outcome of synchronous calls are easily understood but the outcome of asynchronous callbacks for example may not be so easy to determine or link back together.
Some requests may "go off the radar" to later re-surface downstream somewhere else and you will need to design for this if you are to have full traceability of end-to-end asynchronous business processes across distributed systems and services.
Fortunately today there are a number of Open Source products that you can use to log, consolidate and visualise trace data.
Linking Interactions
A common way of linking interactions is to use a unique correlation id (typically a GUID) which is generated and attached (typically as an additional HTTP header) at the start of the journey when a request first arrives at your API gateway.
As long as each part of the journey continues to pass and log the correlation id then you will be able to trace the entire journey once trace data is consolidated.
When a journey breaks to enter an external system that you don't own, to potentially await a callback event of some kind, then you will need to design a mechanism to re-establish the conversation correlation id on re-entry when the callback is invoked.
Tagging Requests
Having linked all your various system interactions together for a request via a correlation id you can further annotate requests by tagging them with useful identifiers such as a customer id or session id that will allow you an alternative means of querying your trace data. You may well find this is a requirement in order to deal with support queries where the correlation id is not known or when you need to analyse multiple interactions related to a specific customer or business journey.
Trace Data Consolidation
In order to make trace data searchable it must first be consolidated centrally and indexed. You may or may not have a requirement for this to be done in near real time but it is essential that logging of trace data is robust so that no data is lost. Extra effort to prove that trace data is not lost under peak loads or when services fail and re-start is always time well spent.
Trace House-Keeping
If your micro-services are handling millions of requests then your trace data can quickly mount up and you will need to put house-keeping procedures in place to purge or further consolidate it periodically.
It's always helpful to understand the nature of the trace data that is generated and so performance and volume testing should be undertaken to understand the exact volumes of data that will be created and to identify any bottlenecks or potential issues in the shipping, consolidation and indexing processes when operating under peak loads. You may need to provision additional storage capacity.
Some trace data can be very verbose and you may wish to only retain the full detail for an agreed period of time before stripping excess content and then finally purging the trace data. Deciding what to retain and for how long should be part of your traceability strategy. You may need to convert verbose trace to summary details to reduce storage costs whilst retaining data for compliance reasons.
Operational Testing
Operational testing should be performed to prove that your trace strategy is correctly in place for all system interactions and that business processes can be fully traced from beginning to end. The data itself can be very revealing and help you to understand how your systems are actually behaving.
Don't let requests to your micro-services come and go without a trace!
